• FBH series Bag Heat sealing machine
| √ | High Efficiency | √ | High Output |
| √ | Small Footprint | √ | Friendly Operation Interface |
| √ | Good Sealing Appearance |
| • Mode Of Bag Top Packaging It is suitable for PE or PP bag with thickness of 0.12-0.32mm | • Sealing Procedure Sequence Dedusting Optional-Heating-Pinching-Cooling |
 |  |
Product Advantages
| High-Efficiency
It has high working efficiency,heat sealer machine by PLC can be programmed automatically complete the whole process of packaging, the speed up to 720 m/hour. |  |
 | Good Sealing Effect
Bag heat sealer machine uses poly tetra fluoro ethylene (Teflon) sealing tape, which is evenly heated by heat conduction and then air-cooled, making the sealing surface of the packaging bag smooth and flat, not easy to stick, and has a good sealing effect. |
| Safety
To ensure safe operation, the machine is equipped with an emergency stop button. Press the emergency stop button on the right side of the machine and the machine will resume. |  |
 | Matching Packaging Line
Heavy-duty heat bag packaging machine can form a production line with a conveyor, and can also form a fully automatic packaging production line with automatic metering, automatic filling, palletizing, arrow threading, strapping and winding processes. |
| Convenience Of After-sales Repair
Excellent after-sale purchase without worryWarranty is one year. | |
Application Field
 |  |  |
| Chemical Industry | Compound Fertilizer Industry | Engineering Plastic Industry |
 |  |  |
| Feed Industry | Food Additives Industry | Medical Intermediate |
| Model | FBH-32 | FBH-32D | FBH-42 | FBH-42D |
| Voltage (V/Hz) | （3PH）AC 380/50 | |||
| Gross Power（KW) | 4 | 4.5 | 5 | 5.5 |
| Transmission Power（KW) | 0.75 | |||
| Heating Power （KW) | 0.5×6 | 0.5×8 | ||
| Deduster Powe（KW) | – | 0.6 | – | 0.6 |
| Sealing Speed (m/min) | 0-12 | |||
| Film Material | PE、PP、film | |||
| Bag Thickness(mm) | ≤0.8 | |||
| Sealing Width (mm) | 8-10 | |||
| Height From Sealing Center to the Floor (mm) | 750-1450 | |||
| Temperature Range(℃) | 0-400 | |||
| Air Source Pressure (Mpa) | 0.6 | |||
| Cooling Type | Air cooling | |||
| Deduster | × | √ | × | √ |
| External Dimension (L×W×H)(mm) | 2830×950×1800 | 3015×950×1800 | ||
| Net Weight (kg) | 320 | 350 | ||
FBH-32 itself comes with a protective cover, so there is no need to add a protective cover
If the customer has no special requirements, the distance is about 20mm
There is no requirement for the bag’s external dimensions, but the distance between the material and the bag mouth when filled with materials must be at least 100mm.
5 meters, 3 meters are not enough
