FBH-S series Bag Heat sealing machine
| √ | High Efficiency | √ | High Output |
| √ | Small Footprint | √ | Friendly operation interface |
| √ | Good Sealing Appearance |
| • Mode Of Bag Top Packaging It is suitable for PE or PP bag with thickness of 0.12-0.32mm | • Sealing Procedure Sequence Heating-Pinching-Cooling |
 |  |
Product Advantages
| High-Efficiency Heat Sealing
As an advanced industrial plastic bag heat sealer, this impulse heat sealer delivers up to 1800 bags/hour with PLC automation. The servo-driven sealing module returns quickly, reducing wait time and boosting sealing speed. |  |
 | The sealing component uses a servo motor and ball screw mechanism for fast reciprocating motion, enabling quick return speeds, reduced waiting time, and significantly improved sealing efficiency. This makes it a reliable choice for users seeking a fast and stable plastic bag sealing machine. |
| Good Appearance And Energy Conservation
This machine uses varnished cloth to separate the packaging bag and the heating device. It is easy to cool after heating, has a smooth surface, is not easy to stick, and has a good sealing surface quality. Pulse temperature control is adopted, which does not require continuous heating and is more energy-efficient. |  |
 | Easy Operation And Maintenance
Designed as a user-friendly industrial plastic bag sealer machine, it features a simple control interface, clear fault alarms, and convenient temperature adjustments. |
| Adopts the clamping mode of the front and rear cylinders to make the seal secure, and the sealing module can be moved out for easy maintenance. |  |
 | Connect With Packaging Line The transmission mechanism of the machine adopts a special clamping chain, equipped with a frequency converter to achieve synchronization between the input of the packaging bag and the operation of the conveyor. It can form a production line with the conveyor, and can form a fully automatic packaging production line with automatic metering, automatic filling, stacking, arrow strapping and winding processes. |
| Convenience Of After-sales Repair Excellent after-sale purchase without worry |
|
Application Field
 |  |  |
| Chemical Industry | Compound Fertilizer Industry | Engineering Plastic Industry |
 |  |  |
| Feed Industry | Food Additives Industry | Medical Intermediate |
| Voltage (V/Hz) | AC 380/50 3PH |
| Gross Power (KW) | 5 |
| Sealing Speed (m/min) | 0-12 |
| Seal Width (mm) | 5 |
| Height From Sealing Center To The Floor (mm) | 800-1400 |
| The Minimum Distance Between The Top Of Bag (mm) | 180 |
| Temperature Range (℃) | 0-300 |
| Gas Source Pressure (Mpa) | 0.6 |
| Heater Move Stroke | 550 |
| Max.bag Width (mm) | 460 |
| Total Thickness of Bag(mm) | ≤0.8 |
| Material of Bag | PE, Polypropylene (PP) |
| Dimensions (LXWXH) (mm) | 2500X1022X1800 |
Routine maintenance is recommended weekly to ensure consistent sealing quality. Click here for more details.
Yes. It supports continuous heavy-duty sealing for high-volume production.
Yes. It is compatible with M-fold and gusseted heavy bags.
No. It has a compact footprint suitable for small and medium factories.
